SIRIUS-i100
General
| Product Name | X-ray nano scanner |
|---|---|
| Model Name | SIRIUS-i100 |
| Use | Analyzing small precision parts and biosensors |
| Feature | Micro CT scanner for 3D imaging with sub-micrometer resolution |
| User |
|
Specifications
| X-ray Source | Microfocus X-ray tube, 20–100 kV, spot size 5 μm @ 7.5 W, maximum 15 W |
|---|---|
| X-ray Detector | sCMOS detector 36.7 x 36.7 mm, 4096 x 4096, 16 million pixels |
| Scan Time | Less than 6 minutes per sample |
| Magnification | 1.2 to 10 times |
| FOV (field of view) | About 3.7 ~ 30mm |
| Resolution | 0.9 ~ 7.5㎛ / pixel |
| Radiation Safety | < 1 μSv/h at any point on the equipment surface |
| Size (WxDxH) | 1000(W) x 800(D) x 570(H) mm |
| Weight | About 250kg |
